PN 10 to PN 250 - 150 Lbs to 1500 Lbs
DN 10 to DN 300 - 3/8" to 1/2"
Some options are not compatible
Special valve can be designed upon request
DN 10 to DN 300
PN 10 to PN 250 - 150 Lbs to 1500 Lbs according to DN
Welded, screwed-on or floating flange
One way, two ways or three ways
Floating or Trunnion ball, fixed or floating seats
Sealed O'rings stuffing box, with pure or filled PTFE rafters, graphite stuffing box, strengthened stuffing box (seal plus packing), security extra stuffing box
25% PTFE glass, graphite, reinforced graphite, stainless steel graphite or stainless steel PTFE spiral, helicoflex®, viton, kalrez®, EPDM...
Graphite filled PTFE, glass filled PTFE, stainless steel PTFE, nylon, polypropylene, peek, TFM1600, TF4215...
Steel, stainless steel, duplex and super duplex, inconel, incoloy®, hastelloy®, titanium, zirconium, uranus®, nickel, monel
Manual, pneumatic (single or double-acting), electrical
